Azure Kubernetes Service (AKS) is a managed Kubernetes service that lets you quickly deploy and manage clusters.

This is a Tutorial on how to deploy a container-based application (Voting-App) using Azure Kubernetes Cluster service.

First, Few very basics about Kubernetes,

Kubernetes is a production-ready, portable, open-source platform for managing containerized workloads and services, that facilitates both declarative configuration and automation.

Basically, Kubernetes is a container orchestration tool When you deploy Kubernetes, you get a cluster. This Cluster has MASTER NODE and WORKER NODEs.

The abbreviation K8s is derived by replacing the eight letters of “ubernete” with the digit 8.

To understand Kubernetes Architecture overview, I post some Images and their Source which are good place to start learning about Kubernetes if you are new to k8s.

Note : This is just overview understand this Application Deployment for this Blog. I have plans to provide more in-depth Kubernetes tutorials coming soon. Consider Following my Blogs.Thx.

1.png Image Source : kubernetes.io/docs/tutorials/kubernetes-bas..

12.png Image Source : edureka.co/blog/kubernetes-tutorial


Image source : collabnix.com/5-minutes-to-kubernetes-archi..

Let's get started with our Deployment,

To-do List :

  • Deploy an AKS(Azure K8s Service) cluster using Azure Portal.
  • Run a multi-container application with a web front-end and a Redis instance in the cluster.(Voting App. taken from Open Source Github Repo: dockersamples/ example-voting-app )

Create Azure Kubernetes Cluster Service using Azure Portal

  • On Azure Portal > Search Kubernetes Service > Create k8s Cluster and It will ask for Product details like Resource Group Name, Cluster Name, Region, Availability Zones, Kubernetes Version, Node Size, Scale Method(AutoScaling), Node Count Range (1-2).
    Configure those as you want then Review + Create As per,
    11.png 22.png

    Note: Primary node pool
    The number and size of nodes in the primary node pool in your cluster. For production workloads, at least 3 nodes are recommended for resiliency. For development or test workloads, only one node is required.

  • Validation passed > Hit Create.
    And We have successfully deployed Azure Kubernetes Cluster with 2 nodes on which we can deploy our Container-based Voting Application. 33.png

Get into Azure Cloud Shell to run our k8s Cluster and Deploy our app.

  • Go to Resource once deployment successful notification popup.

  • Our K8s Cluster (VotingAppCluster) Overview page,

  • Open Azure CLI from the Azure Portal button from top-right corner. Bash Azure Cloud Shell will pop from the bottom,

Note : When you first-time open the Cloud Shell, you will find that it requires you to create a Storage account. The reason for that Storage Account is to persist the scripts, keys, etc that you'll use over and over as you interact with your resources


  • Get access credentials for a managed Kubernetes cluster.

    az aks get-credentials --resource-group YourResourceGroupNAME --name YourAKSClusterNAME



  • Verify the connection to your cluster using the "kubectl get nodes" This command returns a list of the cluster nodes. (We have 2) 88.JPG

Run the Application

  • The sample Azure Vote Python applications.
  • A Redis instance.

  • First Create a file named votingapp.yaml
    I used nano editor to create, Edit, and save .yaml file.


-paste below content into the nano editor for votingapp.yaml file
run > nano votingapp.yaml

apiVersion: apps/v1
kind: Deployment
metadata:
  name: azure-vote-back
spec:
  replicas: 1
  selector:
    matchLabels:
      app: azure-vote-back
  template:
    metadata:
      labels:
        app: azure-vote-back
    spec:
      nodeSelector:
        "kubernetes.io/os": linux
      containers:
      - name: azure-vote-back
        image: mcr.microsoft.com/oss/bitnami/redis:6.0.8
        env:
        - name: ALLOW_EMPTY_PASSWORD
          value: "yes"
        resources:
          requests:
            cpu: 100m
            memory: 128Mi
          limits:
            cpu: 250m
            memory: 256Mi
        ports:
        - containerPort: 6379
          name: redis
---
apiVersion: v1
kind: Service
metadata:
  name: azure-vote-back
spec:
  ports:
  - port: 6379
  selector:
    app: azure-vote-back
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: azure-vote-front
spec:
  replicas: 1
  selector:
    matchLabels:
      app: azure-vote-front
  template:
    metadata:
      labels:
        app: azure-vote-front
    spec:
      nodeSelector:
        "kubernetes.io/os": linux
      containers:
      - name: azure-vote-front
        image: mcr.microsoft.com/azuredocs/azure-vote-front:v1
        resources:
          requests:
            cpu: 100m
            memory: 128Mi
          limits:
            cpu: 250m
            memory: 256Mi
        ports:
        - containerPort: 80
        env:
        - name: REDIS
          value: "azure-vote-back"
---
apiVersion: v1
kind: Service
metadata:
  name: azure-vote-front
spec:
  type: LoadBalancer
  ports:
  - port: 80
  selector:
    app: azure-vote-front
  • Paste the Above Copied content in there.
  • Cnt + 0 to save file [Wrote 85 lines] in my .yaml
    and Cnt + z to exit out.


  • Deploy the application using the "kubectl apply" specify the name of your YAML manifest file. as per,
    kubectl apply -f votingapp.yaml

  • Our Voting App is deployed successfully when you get that "azure-vote-back" and "azure-vote-front" get created.


Now it's about time to TEST Out the App.

  • We need the Public IP Address. To get our deployment has created an external IP, run below command,
 kubectl get service azure-vote-front --watch

This shows our Application's external Public IP address.
My App's External-IP = 52.190.47.180


  • Copy External-IP (52.190.47.180 ) and paste it on your Browser

Final Deployed App.png

You got that. This App is deployed on 2 Cluster Nodes with high availibility and resiliency.

  • Nodes and Cluster Monitoring for our Voting App Under AKS > Cluster Insight / Monitor Tabs respectively.

Node Monitors 1.png

Node Monitors 2.png

Success.

Azure Kubernetes Cluster Service,

  • It is a fully managed Kubernetes Cluster Service. Deploy a managed Kubernetes cluster in Azure. – Reduces the complexity and operation overhead of managing K8s by offloading much of that responsibility to Azure
  • Azure AKS Cluster Handles critical operations tasks like load balancing, scaling, health monitoring, and maintenance for you.

I am on my continuous learning quest and Kubernetes is in the top list. I apologize if I may have missed some key details or explained less on some commands performed above.
I will be coming up with more in-depth tutorials and blogs about Kubernetes and DevOps in future content.

Hope you have followed along and like the Blog about
Deploy "Voting App" using Azure Kubernetes Cluster Service

Let me know if you have any questions or suggestions to improve my knowledge.

Thanks for your time.
